Barrel Vault Framing
Discipline — Curved Framing
Focus — Geometry / Rhythm / Structure
Overview
Construction-stage photographs reveal the ribs, repetitive layout, and changing geometry behind a barrel-vaulted ceiling.
Seen in the photographs
Subject — Curved timber framing
A continuous curve formed by closely spaced framing members
Views into the structure before finishes conceal the assembly
Transitions between the curved ceiling and surrounding framing
A closer look
Curved ribs during framing
Vault structure and adjoining members
